Model: FY-3L
Speed: 130-180m/min
Finished Facial Unfold Size: 200*200mm/200*210mm/210*210mm
Finished Facial Fold Size: 200*100mm (customized)
This model FY-3L facial tissue pumping paper folding machine is cut by the knife roll after cutting the raw paper,folded into a chain of rectangular cross tissues. Machine with synchronous belt drive, transmission speed before and after the ratio, so that equipment suitable for a variety of base paper needs, greatly improving the quality and efficiency.
1. Facial tissue paper machine
2. Facial paper packing machine
1. This machine adopts vacuum suction folding, automatic counting function stack, with a high speed, neatly folded, and easy operation.
2. The machine is equipped with a tension adjustment device to ensure the finished product size accuracy.
3. Broken paper automatic shutdown system, to avoid paperless or broken paper to produce waste.
|
Item |
FY-3L |
|
Raw Paper Weight |
12-30g/m2 Tissue Roll |
|
Raw Paper Width |
600 mm |
|
Raw Paper Diameter |
1300 mm |
|
Paper Core Diameter |
76.2 mm |
|
Finished Facial Unfold Size |
200*200mm/200*210mm/210*210mm |
|
Finished Facial Fold Size |
200*100mm (customized) |
|
Upper Blade |
Pneumatic Spiral Blade |
|
Host Power |
3 kw |
|
Folding |
Vacuum Absorption |
|
Vacuum System |
7.5 kw |
|
Controller |
Electromagnetic Speed |
|
Production Speed |
130-180 m/min |
|
Cutting System |
Pneumatic Point Cut, Full Cut |
|
Counting |
Automatic |
|
Paper Broken |
Photoelectric Eye |
|
Voltage |
AC380V, 50HZ |
